Technical Data:
|
Product Name |
High Efficiency Universal Crusher/Icing Sugar Pulverizer/sugar crushing mill |
||||
|
Model |
HX-20 |
HX-30 |
HX-40 |
HX-60 |
HX-80 |
|
Capacity(kg/h) |
20--150 |
30--300 |
40--800 |
80--1200 |
150--2000 |
|
Speed of principal axis(rpm) |
4500 |
3800 |
3400 |
3000 |
2100 |
|
Size of input granuless(mm) |
6 |
10 |
12 |
15 |
20 |
|
Crushing Fineness(mesh) |
12--120mesh |
||||
|
Motor power(kw) |
4 |
5.5--7.5 |
7.5--11 |
18.5--22 |
30--37 |
|
Overall Size(L*W*H)(mm) |
700*900*1500 |
800*1100*1700 |
850*1200*1850 |
950*1300*1950 |
1100*1000*2100 |
|
Weight(kg) |
250 |
350 |
450 |
800 |
1200 |
|
Application: |
medical,pesticide,food and provision industries | ||||
Advantage:
It makes use of the high-speed relative movement of the movable fluted disc and the fixed fluted disc to crush the materials through the comprehensive effect of striking and friction of the fluted disc as well as the mutual striking of the materials.Since it features a simple structure,firm and stable operation and good crushing effect,the crushed matterials can be discharged directly apertures.Besides,the whole machine is made of stainless steel.Theinner surface of the enclosure becomes smooth through processing,thus changing the powder residual phenomenon dus to the coarse inner surface of the previous models.As a result,the production of medicine,food and chemical products can better conform to the state standard and the GMP requirements
other product link:
About our factory:
Jiangyin Huixu Powder Machinery Manufacturing Co.,Ltd
Located in the Zhutang Town of Jiangyin city,Jiangsu province.The company has a professional technical team and strong technical force.Our company's productions mainly include six major categories sush as pulverizer ,mixer,dryer,sifter,granulator and so on.Productions are widely used in food, medicine, chemical industry. Our company always take the "quality first" as the purpose.
Warmly welcome foreign friends to our company for visiting and guidance.
Packing and Shipping:
| Remark | small machine LCL freight | big machine FCL frieght |
| Packing | The normal package is wooden box(Size: L*W*H) or pack it according to customers special request. | Fix the machine inside container with steel wires Machine won't move inside the container. |
| Shipping | FOB Shanghai Sea Port or according to customer request | |
Certificates:
FAQ:
A. Detail requirements
When you want to send enquiry to us ,please answer below questions first
1.show me your material with the characteristics and sizes
2. tell me the fineness you want ( size :mesh or mm both is ok)
3. tell me your ideal capacity kg/h
B. Technical service
1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.
C. After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year’s warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty.
